Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm

صورة كبيرة : Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm

تفاصيل المنتج:

مكان المنشأ:	China
اسم العلامة التجارية:	MilkyWay
إصدار الشهادات:	ISO9001/BV/
رقم الموديل:	Galvanized Steel Pole

شروط الدفع والشحن:

الحد الأدنى لكمية:	1 pcs
الأسعار:	Negotiation
تفاصيل التغليف:	As customer request
وقت التسليم:	20 working days after received your payment
شروط الدفع:	T/T, L/C at sight
القدرة على العرض:	300pcs per day

اتصل

مفصلة وصف المنتج

Product Name:	Galvanized Steel Pole	Wind Speed:	30m/s
Welding standard:	AWS D 1.1 /BS EN 1011-1,BS EN 1011-2	Design:	Customized
Material:	Q345	Lift time:	50 years
Warranty:	15 years
تسليط الضوء:	galvanised steel poles,power line pole , power line pole

Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm

Description:

We Are Manufacturer of high quality Seamless Steel Pipe Seamless Steel Pipe type including single and double arms, round ,hexagonal and octagonal type, about the thickness and height we can do as specifc demands.

Specifications:

Height	From 6 m to 15 m
Suit for	Airport ,seaport,plaza,stadium ,square,highway, street way etc
Shape	Conoid ,Multi-pyramidal,Columniform,polygonal or conical
Material	Usually Q345B/A572,minimum yield strength>=345n/mm2 Q235B/A36,minimum yield strength>=235n/mm2 As well as Hot rolled coil from Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, to ST52-
Lamp power	20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz
Torlance of the dimenstion	+- 2%
Optical assembly of lighting fixture	IP 65
Electroshock resistant protective grade	Grade Ⅰ
The casing anti-corrosion performance	Class Ⅱ
Working atmosphere of lighting fixture	-35 ℃~+45 ℃
Surface treatment	Hot dip galvanized Following ASTM A 123, color polyester power or any other standard by client required.
Joint of Poles	Insert mode,innerflange mode,face to face joint mode
Design of pole	Against earthquake of 8 grade
Wind Speed	160 Km/Hour
Minimum yield strength	355 mpa
Minimum ultimate tensile strength	490 mpa
Max ultimate tensile strength	620 mpa
Standard	ISO 9001
Length of per section	Within 14m once forming without slip joint
Welding	We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1
Thickness	1 mm to 30 mm
Style	Size and styles are veriable as per customer request

Design:We have our standard pole with our design,OEM and ODM is also accpetable

Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm 0

Packages:Standard seaworthy

Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm 1

Application:
Highway Seamless Steel Pipe Park Seamless Steel Pipe
Main Roads Seamless Steel Pipe Dock Seamless Steel Pipe
Secondary Roads Seamless Steel Pipe Stadium Seamless Steel Pipe
Storage-yar Seamless Steel Pipe Overpass Seamless Steel Pipe
Industrial-Plant Seamless Steel Toll-Station Seamless Steel Pipe

Hexagonal 5m Powder Coating Galvanized Steel Pole One Section with One Cross Arm 2

Company Introduction:

JiangSu Milky Way Steel Poles Co., Ltd.was established in 1988, is located in Yixing City, Jiangsu Province, Wan Shi Town, covering an area of 35,000 square meters, annual output value reached 200 million . We have 20 years experience in design and production. Our main products are power pole, communication towers, street lighting poles, steel bracket and so on. The company has strong technical force, advanced production equipment, perfect quality management system, product quality has reached international advanced level.
