ASTM A572 GR50 15m 16m عمود فولاذي أنبوبي لمشروع خط توزيع الطاقة
ASTM A572 GR50 15m Steel Tubular Pole For Power Distribution Line Project Production Process Our factory own advance production line, machine including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All the purpose is to produce good quality steel poles. The fabrication process as cut plate, bending, forming, automatic welding, drill holes, quality check before galvanized, hot dip galvanized and
11m 7.2mm 3.8mm 69kv قطب أنبوبي فولاذي لخط النقل
1.Top diameter:80-200mm 2.Bottom diameter:200-400mm 3.Thickness:4mm 5mm 4.Material:Low alloy steel,yield strength not less than 345mpa(GB/T1591-2008standard) C≤0.20,Mn≤1.70,Si≤0.50,P≤0.50,S≤0.0345 5.Marks:Nane plate through rivert or glue ,engrave ,emboss as per customer requirement 6.Welding :We has past flaw testing.Internal and external double welding makes the welding beautiful in shape Welding Standard :AWS ( American Welding Society ) D 1.1 Penetration :100% Advantage
أعمدة خط نقل المضلع 2.5 مم 69 كيلوفولت
Description 1. Top diameter:120mm 2. Bottom diameter:225mm 3. Thickness:7.2mm 4. Shape:Octogonal 5. Material:S355JR S275JR Design service available,just offer design parameter Certificate ISO 9001:2008,etc Destruction test Available welding method CO2 welding or submerged arc auto welding OEM Available Wind pressure 5-300KM/H Pre-shipment test Available Production Progress Raw material test → Cutting →Molding or bending →Welidng (longitudinal )→Dimension verify →Flange
خط التوزيع 9 م 5.5 مم قطب فولاذي أنبوبي مع FRP
To assure our products qualified ,we take steps as follows : 1. Management team : We have employ the foreign export to take chaege of the overall managemnt ,especailly the technical managemnt and quality management . 2. Introducing ISO management ,We are awared ISO 9001:2008 certificate. 3. QC Inpection:It is our company policy that all the finish product should be inspected by our specialzed QC in every manufacure steps and beofore every shipment. Specification of poles
خط نقل HDG 10 مم 160 كم / ساعة قطب أنبوبي فولاذي
Production Progress Our factory own advance production line, machine including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All the purpose is to produce good quality steel poles. The fabrication process as cut plate, bending, forming, automatic welding, drill holes, quality check before galvanized, hot dip galvanized and powder coating, finally quality check according by client’s required.
16m معدن مجلفن نقل القطب الصلب أنبوبي
Material: Hot rolled steel, Q235,Q345,S235,S355,SS400,Gr 50 Yield strength of Material: Minimum yield strength>=235n/mm2 for Q235, S235 and SS400 Minimum yield strength>=345n/mm2 for Q345 S355 and Gr 50 Pole’s height: 3m –15m Length of one part Within 16m once forming without slip joint Wall thickness: 2.3mm-30mm Pole's Shape Can be made: Round, Polygonal, Taper Octagonal, Taper round, Round conical, Taper Square, Square. Arm type can be made: Single arm, Double arm, Tri-arm,
عمود الطاقة الكهربائية المضلع ذو الدائرة الواحدة 18 م لمشروع خط التوزيع
Overseas Project For Electric Pole Country Utility Name Voltage Level Type Year of supply Philippines NEA,NGCP 69KV 25FT-100FT,According to customer requirement Every Month Costa Rica Electric Pole 10M,11M Every Month Congo Electric Pole 8M,10M Every Month Ghana Ghana Elercity Company 11m,12m 2016 Ghana Ghana Elercity Company 10m,11m 2015 Pakistan Wapda 132kv SPA,SPD,SPG 2013 Saudi Arabic Saudi Electricity Company 10m electric pole 2011 Ecuador Celec 138kv PP-B40 2009 More
معدن 230kv 6-10mm سمك القطب المضلع
Specifications 1. Protecion class: IP65 2. Light source: 100W-400W high-pressure sodium lamp 3. Rated voltage and frequency: 220V(±10%)/50Hz 4. Caliber: 60mm 5. Protecting class against eletric shock: Type I 6. Lamp in die-cast aluminum, coated with powder polyes ter after anti-corrosive treatment 7. A lamp body with a built-ray lens 8. Fasteners screws, all stainless steel 9. Applicable height: 6m-12m (according to customers' requirment) 10. Working environment:-35°C--+55°C
30 م معدن مجلفن 10 مم أعمدة نقل الطاقة
Specifications 1. Protecion class: IP65 2. Light source: 100W-400W high-pressure sodium lamp 3. Rated voltage and frequency: 220V(±10%)/50Hz 4. Caliber: 60mm 5. Protecting class against eletric shock: Type I 6. Lamp in die-cast aluminum, coated with powder polyes ter after anti-corrosive treatment 7. A lamp body with a built-ray lens 8. Fasteners screws, all stainless steel 9. Applicable height: 6m-12m (according to customers' requirment) 10. Working environment:-35°C--+55°C
